PM Components
PM Isolator-Filter-WDM / PMIWDM
PM Isolator-Filter-WDM / PMIWDM with integrated design, low loss, dual isolation, anti-interference.
Power1
Wavelength1540
FiberPM1550 or Specify
PackageApplication-specific package
Spec, sample and MOQ review
Export documentation
NDA available on request
Product overview
Designed around the optical requirement.
PM Isolator-Filter-WDM / PMIWDM with integrated design, low loss, dual isolation, anti-interference.
Final performance is confirmed against the selected model, fiber, package and application conditions. Please include wavelength, power, polarization, fiber type, package and expected quantity when requesting a quote.
Key features
What this product delivers.
Feature set and final configuration are confirmed against the selected model and application.
Integrated design, low loss
Dual isolation, anti-interference
Compact structure, high stability
High power adaptability
Specifications
Typical performance
Values below are a starting point. Final parameters are confirmed in the quotation.
Pass Wavelength
nm
1540
Operating Wavelength Range
nm
± 1
Max. Insertion Loss (SMF-28)
dB
0.8 / 0.8
Min. Extinction Ratio
dB
20 / 20
Min. Isolation
dB
22 / 38.0
Min. Filter Passband Isolation
dB
25
Reflect Wavelength Range
nm
1560
Max. Pump Port Insertion Loss
dB
0.6 / 0.6
Min. Pump Extinction Ratio
dB
18
Min. Pump Isolation
dB
12
Min. Return Loss
dB
50
Max. Optical Power
W
1
Max. Peak Power for ns pulse
kW
5
Max. Tensile Load
N
5
Fiber Type
PM1550 or Specify
Operating Temperature
C
-40 to +70
Storage Temperature
C
-40 to +85
RFQ
Request this product
Send your target specifications, quantity, application and delivery country. Our team will respond with a suitable configuration.
