Polarization Maintaining Isolator – 1550 nm
Polarization Maintaining Isolator – 1550 nm with low forward insertion loss, high reverse isolation.
Power6
Wavelength1550
FiberPM1550 or Specify
PackageApplication-specific package
Spec, sample and MOQ review
Export documentation
NDA available on request
Product overview
Designed around the optical requirement.
Polarization Maintaining Isolator – 1550 nm with low forward insertion loss, high reverse isolation.
Final performance is confirmed against the selected model, fiber, package and application conditions. Please include wavelength, power, polarization, fiber type, package and expected quantity when requesting a quote.
Key features
What this product delivers.
Feature set and final configuration are confirmed against the selected model and application.
Low forward insertion loss
High reverse isolation
Vibration and thermal resistance, stable polarization
High power handling
Specifications
Typical performance
Values below are a starting point. Final parameters are confirmed in the quotation.
Center Wavelength
nm
1550
Operating Wavelength Range
nm
λc ± 20
Typ. Insertion Loss
dB
0.5 / 0.6
Max. Insertion Loss
dB
0.7 / 0.8
Typ. Peak Isolation
dB
32 / 50
Min. Isolation
dB
25 / 43
Min. Extinction Ratio
dB
22
Min. Return Loss
dB
50
Max. Optical Power
W
6
Max. Peak Power for ns pulse
kW
10
Max. Tensile Load
N
5
Fiber Type
PM1550 or Specify
Operating Temperature
C
-40 to +70
Storage Temperature
C
-40 to +85
RFQ
Request this product
Send your target specifications, quantity, application and delivery country. Our team will respond with a suitable configuration.
