PM Components
High Power Polarization Maintaining Optical Circulator
High Power Polarization Maintaining Optical Circulator with high power handling, high isolation degree and high extinction ratio.
Power10
Wavelength1550
FiberZBL fiber
PackageApplication-specific package
Spec, sample and MOQ review
Export documentation
NDA available on request
Product overview
Designed around the optical requirement.
High Power Polarization Maintaining Optical Circulator with high power handling, high isolation degree and high extinction ratio.
Final performance is confirmed against the selected model, fiber, package and application conditions. Please include wavelength, power, polarization, fiber type, package and expected quantity when requesting a quote.
Key features
What this product delivers.
Feature set and final configuration are confirmed against the selected model and application.
High power handling
High isolation degree and High extinction ratio
Low insertion loss
Fiber type optional
Specifications
Typical performance
Values below are a starting point. Final parameters are confirmed in the quotation.
Center Wavelength (λc)
nm
1550
Operating Wavelength Range
nm
λc ± 10
Max. Insertion Loss
dB
0.8
Min. Isolation, P 2-P 1, 23 ℃
dB
40
Min. Isolation, P 3-P 2, 23 ℃
dB
40
Min. Crosstalk
dB
65
Min. Return Loss
dB
55
Max. Optical Power
W
10
Max. Peak Power for ns pulse
kW
10
Max. Tensile Load
N
5
Fiber Type
Corning ClearCurve
ZBL fiber
Operating Temperature
℃
0 to +70
Storage Temperature
℃
- 40 to +85
RFQ
Request this product
Send your target specifications, quantity, application and delivery country. Our team will respond with a suitable configuration.
