PM Components
High Power Polarization Independent Circulator
High Power Polarization Independent Circulator with low insertionloss, high isolation degree and high extinction ratio.
Power500
Wavelength461 / 532
FiberNufern 460-HP
PackageApplication-specific package
Spec, sample and MOQ review
Export documentation
NDA available on request
Product overview
Designed around the optical requirement.
High Power Polarization Independent Circulator with low insertionloss, high isolation degree and high extinction ratio.
Final performance is confirmed against the selected model, fiber, package and application conditions. Please include wavelength, power, polarization, fiber type, package and expected quantity when requesting a quote.
Key features
What this product delivers.
Feature set and final configuration are confirmed against the selected model and application.
Low insertionloss
High isolation degree and High extinction ratio
Good stability and High environmental stability
High Power Handling
Specifications
Typical performance
Values below are a starting point. Final parameters are confirmed in the quotation.
Center Wavelength
nm
461 / 532
Typ. Insertion Loss
dB
1.0 / 0.8
Max. Insertion Loss
dB
1.4 / 1.2
Min. Isolation P2 to P1
dB
23
Min. Isolation P3 to P2
dB
23
Min. Crosstalk P1 to P3
dB
50
Min. Return Loss
dB
50
Max. Polarization Dependent Loss
dB
0.15
Max. Optical Power (CW)
mW
500
Max. Tensile Load
N
5
Fiber Type
Nufern 460-HP
Operating Temperature
C
10 to +50
Storage Temperature
C
0 to +60
RFQ
Request this product
Send your target specifications, quantity, application and delivery country. Our team will respond with a suitable configuration.
