FBG & Raman
High Power Fiber Bragg Grating – Special Wavelength
High Power Fiber Bragg Grating – Special Wavelength with high sensitivity, not affected by electromagnetic interference.
Power60 / 150 / 300
Wavelength1550 / 1927 / 1936 / 1940
FiberX/125 & 130 / X/250 / X/400
Package60 × 12 × 6.5 or recoating
Spec, sample and MOQ review
Export documentation
NDA available on request
Product overview
Designed around the optical requirement.
High Power Fiber Bragg Grating – Special Wavelength with high sensitivity, not affected by electromagnetic interference.
Final performance is confirmed against the selected model, fiber, package and application conditions. Please include wavelength, power, polarization, fiber type, package and expected quantity when requesting a quote.
Key features
What this product delivers.
Feature set and final configuration are confirmed against the selected model and application.
High sensitivity
Not affected by electromagnetic interference
Good stability
Small size
Specifications
Typical performance
Values below are a starting point. Final parameters are confirmed in the quotation.
Port Configuration
1x1
Signal Wavelength
nm
1550 / 1927 / 1936 / 1940
3 dB Bandwidth
nm
0.1 to 4
Wavelength Matching for HR-OC
nm
0.2
Fiber Type
µm
X/125 & 130 / X/250 / X/400
Signal Reflectivity (Fundamental mode)
%
HR ≥ 99.8 / OC 3 to 20 / HR ≥ 99.5 / OC 3 to 20 / HR ≥ 99.5 / OC 3 to 20
Max Power Handling
W
60 / 150 / 300
Max Signal Handling
W
30 / 70 / 150
Pump Transmittance
%
≥ 99
Package Dimension
mm
60 × 12 × 6.5 or recoating
Operating Temperature
C
0 to 75, RH ≤ 55%
Storage Temperature
C
-40 to 85, RH ≤ 55%
RFQ
Request this product
Send your target specifications, quantity, application and delivery country. Our team will respond with a suitable configuration.
